Spicer 4-53-61 Driveshaft Midship Stub Shaft 1550 Series 3.5"x.095" 1.750x16 Spl

Spicer 4-53-61 Driveshaft Midship Stub Shaft 1550 Series 3.5"x.095" 1.750x16 Spl

Part # / SKU: 4-53-61S

Brand: Spicer

$199.22 USD
$199.22 USD
Sale Sold out
Shipping calculated at checkout.
Stock Available: 1

Brand: Spicer

For Use With: Outboard Slip Yoke

Series: 1550

Spline O.D.: 1.7500

Number Of Splines: 16

Involute: No

Fits Tube Diameter: 3.5

Fits Tube Wall: 0.095

Spline End To Brg Shoulder (Y): 7.469

Spline End To Weld (K) In.: 8.562

Spline Length (L) In.: 5.938

Shoulder Diameter (B) In.: 2.188

Shoulder Length (G) In.: 0.812

Bearing Diameter (C) In.: 1.772

Butt Diameter: 3.321

Style: 1

Bearing Diameter (Max): 1.7721

Bearing Diameter (Min): 1.7716
