Spicer 4-2-689 Driveshaft Flange Yoke 1550 8x .375 Holes on 6.125BC 6.625M pilot
Spicer 4-2-689 Driveshaft Flange Yoke 1550 8x .375 Holes on 6.125BC 6.625M pilot
Brand: Spicer
Couldn't load pickup availability
Made in USA
Brand: Spicer
Series: 1550
Flange Or Swing Dia. In. (A): 6.875
Bolt Circle Dia. In. (B): 6.125
Bolt Hole Dia. In (B): .375 - DRILLED
Number Of Bolt Holes: 8
Pilot Dia. M=Male F=Female (C): 6.625 - MALE
Flange Face To C/L In. (G): 2.000
Outside Yoke Dimension In.(E): 5.25
Yoke Bearing Dimension In. (D): 1.375
Design: Circular
Joint Angle #1: 22
Fast shipping from Florida to USA Contiguous
1 year warranty
OE Spec
ISO 9001 Quality control
