Spicer 350-53-23770 Driveshaft Midship Stub Shaft SPL350 Series 68 Spline
Spicer 350-53-23770 Driveshaft Midship Stub Shaft SPL350 Series 68 Spline
Brand: Spicer
Couldn't load pickup availability
Brand Spicer
For Use With End Yoke Or Companion Flange
Series SPL350
Invoice Midship tube shaft
Material Steel
Spline O.D. 2.707
Number Of Splines 68 I
Involute Y
Fits Tube Diameter 140.000MM
Fits Tube Wall .083
Spline End To Brg Shoulder (Y) 3.366
Spline End To Weld (K) In. 5.020
Spline Length (L) In. 2.244
Thread Size M38X1.5-6G
Shoulder Diameter (B) In. 3.130
Shoulder Length (G) In. .216
Bearing Diameter (C) In. 2.756
VMRS 024002060
Butt Diameter 5.14
Style 1
Bearing Diameter (Max) 2.756
Bearing Diameter (Min) 2.755
Fast shipping from Florida
Care Instructions
Care Instructions
All of our parts are packaged to the best of our ability. If you receive an item with inferior packaging, please let us know so that we can improve the delivery and our service to you as the customer
Shipping & Returns
Shipping & Returns
This item can be returned within 30 days of purchase. You are responsible for returning the item. No returns are accepted if rubber boots have been torn or damaged during installation. Please contact us if you are unsure of fitment prior to purchase
-
-
Check the OEM # of your part before you purchase
If you have no idea what the original part number is for your Driveshaft, CV Joint or Component - contact us for the appropriate diagram or for assistance. We are here to help!
For orders with a cart value over $1000 contact us using the chat button below to reduce your shipping costs using our freight service
