Spicer 3-53-1361 Driveshaft Midship Stub Shaft 1310-1410 Series 3" x .083" Tube
Spicer 3-53-1361 Driveshaft Midship Stub Shaft 1310-1410 Series 3" x .083" Tube
Brand: Spicer
Couldn't load pickup availability
Brand: Spicer
For Use With: Outboard Slip Yoke
Series: 1310-1410
Spline O.D.: 1.3750
Number Of Splines: 16
Involute: No
Fits Tube Diameter: 3
Fits Tube Wall: 0.083
Spline End To Brg Shoulder (Y): 6.750
Spline End To Weld (K) In.: 8.094
Spline Length (L) In.: 4.969
Shoulder Diameter (B) In.: 1.719
Shoulder Length (G) In.: 1.125
Bearing Diameter (C) In.: 1.378
Butt Diameter: 2.845
Style: 1
Bearing Diameter (Max): 1.3784
Bearing Diameter (Min): 1.3779
Bearing Diameter Length: 1.78
