Spicer 3-1-1023-3 Circular Drive Shaft Companion Flange 1350 Series 2.250 Bore
Spicer 3-1-1023-3 Circular Drive Shaft Companion Flange 1350 Series 2.250 Bore
Couldn't load pickup availability
3-1-1023-3 Drive Shaft Companion Flange
Brand Spicer
Flange Type Circular
Series 1350
Flange Width Diameter (A) In. 4.56
Bolt Circle Diameter (B) In. 3.750
Number Of Holes 4
Bore Diameter (D) In. 2.250
Key Width (K) In. 0.625
Pilot Diameter (C) In. 2.750 - FEMALE
Set Screw Hole Diameter In. 0.500
Hub Diameter (E) In. 4.562
Circ Flnge Face To End Of Hub 3.000
Bolt Hole Diameter (In.) .438-20 - TAPPED
Material Steel
VMRS 024002040
Actual Hole Diameter (Max) 2.251
Actual Hole Diameter (Min) 2.250
Package Type EACH
Package Qty 1
Weight 10.25 LB
Country of Origin United States
Care Instructions
Care Instructions
All of our parts are packaged to the best of our ability. If you receive an item with inferior packaging, please let us know so that we can improve the delivery and our service to you as the customer
Shipping & Returns
Shipping & Returns
This item can be returned within 30 days of purchase. You are responsible for returning the item. No returns are accepted if rubber boots have been torn or damaged during installation. Please contact us if you are unsure of fitment prior to purchase
For orders with a cart value over $1000 contact us using the chat button below to reduce your shipping costs using our freight service
-
Free Shipping
We will cover the shipping costs on this item to all the USA contiguous States. We have you covered!
-
Check the OEM # of your part before you purchase
If you have no idea what the original part number is for your Driveshaft, CV Joint or Component - contact us for the appropriate diagram or for assistance. We are here to help!
