Spicer 2-1-283 Driveshaft Companion Flange 1310 Series BCD 3.125"
Spicer 2-1-283 Driveshaft Companion Flange 1310 Series BCD 3.125"

Spicer 2-1-283 Driveshaft Companion Flange 1310 Series BCD 3.125"

SKU: 2-1-283S
Regular price
$181.00
Sale price
$181.00
Shipping calculated at checkout.

Made in USA

Brand: Spicer

Flange Type: Rectangular

Series: 1310

Flange Width Diameter (A) In.: 3.875

Bolt Circle Diameter (B) In.: 3.125

Number Of Holes: 4

Bore Diameter (D) In.: 1.000

Key Width (K) In.: 0.250

Pilot Diameter (C) In.: 2.375 - FEMALE

Set Screw Hole Diameter In.: 0.375

Set Loc. ( Hub & Keyway At 12): 6

Hub Diameter (E) In.: 1.875

Rect Lngth Thru Hole (F): 1.500

Rect Flnge Face End Of Hub (G): 2.062

Circ Flnge Face To End Of Hub: 2.062

Actual Hole Diameter (Max): 1.0005

Actual Hole Diameter (Min): 0.9995

Actual Keyway Width (Max): 0.253

Actual Keyway Width (Min): 0.251

Fast shipping from Florida to USA Contiguous

Tracking number provided

OE Spec
