Spicer 170-4-691-1X Driveshaft Differential End Yoke SPL170 Series 39 Splines

Spicer 170-4-691-1X Driveshaft Differential End Yoke SPL170 Series 39 Splines

Part # / SKU: 170-4-691-1XS

Brand: Spicer

Regular price $268.21 USD
Regular price Sale price $268.21 USD
Sale Sold out
Shipping calculated at checkout.
Stock Available: 1
Brand Spicer
Series SPL170
Spline Count 39
Yoke Style HR
Hub Diameter R 3.000
C/L To End Hub S 6.391
Type Splined Hole
Outside Yoke Dimension (In) E 6.456
Yoke Bearing Dimension (In) D 2.166
Major Diameter 2.024
Involute Spline N
VMRS 022003072
Length Thru Hole Q 2.312
C-Bore Depth 0.105

Fast shipping from Florida

Care Instructions

All of our parts are packaged to the best of our ability. If you receive an item with inferior packaging, please let us know so that we can improve the delivery and our service to you as the customer

Shipping & Returns

This item can be returned within 30 days of purchase. You are responsible for returning the item. No returns are accepted if rubber boots have been torn or damaged during installation. Please contact us if you are unsure of fitment prior to purchase

View full details

End Yoke Diagram

  • Check the OEM # of your part before you purchase

    If you have no idea what the original part number is for your Driveshaft, CV Joint or Component - contact us for the appropriate diagram or for assistance. We are here to help!
