Spicer 10-4-93 Power Take Off (PTO) End Yoke 1000 Series 1.000" x .250 Keyway
Spicer 10-4-93 Power Take Off (PTO) End Yoke 1000 Series 1.000" x .250 Keyway
Brand: Spicer
Couldn't load pickup availability
Brand New Genuine Spicer PTO End Yoke
|
Brand |
Spicer |
|
Series |
1000 |
|
Yoke Style |
ISR |
|
Hub Diameter R |
2.000 |
|
C/L To End Hub S |
2.500 |
|
Type |
Straight Round Hole |
|
Inside Yoke Dimension (In) K |
1.500 |
|
Yoke Bearing Dimension (In) D |
0.938 |
|
Hole Diameter (In) P |
1.000 |
|
Sae Keyway Width (In) X |
0.250 |
|
Set Screw Hole Diameter (In) |
0.375 |
|
Keyway Location W |
3 |
|
Set Screw Location W |
9 |
|
Length Thru Hole Q |
1.030 |
|
Joint Angle #1 |
60 |
