Flange - Toyota HILUX Pickup SR5 ISR 56mm x 64mm 2.204" x 2.519" Pilot 1.811M
Flange - Toyota HILUX Pickup SR5 ISR 56mm x 64mm 2.204" x 2.519" Pilot 1.811M
Couldn't load pickup availability
Flange - Toyota HILUX Pickup SR5 ISR 56mm x 64mm 2.204 x 2.519 Pilot 1.811M
56x64
This flange uses Inside Type Snap Rings
There are several commonly used Toyota Flanges - please compare measurements before purchase
This can be done by taking the centerline of each hole and measuring as per the attached diagrams
Holes 4
Series Toyota (1.142 x 2.047 I/C)
(OD) 4.173
Pilot 1.811 Male
(H) 1.456
(X) 2.204
(Y) 2.519
(Z) 3.346
Care Instructions
Care Instructions
All of our parts are packaged to the best of our ability. If you receive an item with inferior packaging, please let us know so that we can improve the delivery and our service to you as the customer
Shipping & Returns
Shipping & Returns
This item can be returned within 30 days of purchase. You are responsible for returning the item. No returns are accepted if rubber boots have been torn or damaged during installation. Please contact us if you are unsure of fitment prior to purchase




For orders with a cart value over $1000 contact us using the chat button below to reduce your shipping costs using our freight service
-
Free Shipping
We will cover the shipping costs on this item to all the USA contiguous States. We have you covered!
-
Check the OEM # of your part before you purchase
If you have no idea what the original part number is for your Driveshaft, CV Joint or Component - contact us for the appropriate diagram or for assistance. We are here to help!
