Driveshaft Flange Yoke 1310 series, 4x0.488 Holes on 3.500BC, 2.000F 2-2-939

Driveshaft Flange Yoke 1310 series, 4x0.488 Holes on 3.500BC, 2.000F 2-2-939

SKU: 2-2-939-EB-USA-M
Regular price
Sold out
Sale price
$31.68
Shipping calculated at checkout.

Flange Yoke - 1310 series

Series

1310

Flange Or Swing Dia. In. (A)

4.500

Bolt Circle Dia. In. (B)

3.500

Bolt Hole Dia. In (B)

.500 - DRILLED

Number Of Bolt Holes

4

Pilot Dia. M=Male F=Female (C)

2.000 - FEMALE

Flange Face To C/L In. (G)

1.650

Material

Steel

Outside Yoke Dimension In. (E)

3.469

Yoke Bearing Dimension In. (D)

1.062

Design

Square

Flanges

Holes 4

Series 1310 (1.062 x 3.219)

(OD) 4.500

Pilot 2.000F

(H) 1.650

(X) 2.475

(Y) 2.475

(Z) 3.500

This is a High-Quality DSP Brand Flange Yolk that has a one year warranty.
