CV JOINT (with 26 Spline Stub OD 100mm) H-32MM MERCEDES END ML W163 - 027SG80002

CV JOINT (with 26 Spline Stub OD 100mm) H-32MM MERCEDES END ML W163 - 027SG80002

Part # / SKU: K1345

Brand: Mako

Regular price $74.25 USD
Regular price Sale price $74.25 USD
Sale Sold out
Shipping calculated at checkout.
Stock Available: 16

CV JOINT (26-100) H-32MM, MERCEDES END, + SHAFT R.63MM, ML W163

This Kit includes the weld on spline stub

CV Joint number of teeth 26

External diameter 100 mm - 3.937"

Joint width 32 mm - 1.26"

Internal diameter 29 mm

Spline length 27.8 mm

Hole diameter: 8 mm

Number of holes: 6

Pitch diameter 86 mm

large hole diameter A: 100mm

Small hole diameter B: 26mm

Plate height Hm: 44mm

Total height H: 60mm

SHAFT Splines: 26

Tube spline diameter: 60.55 mm

Shaft length: 135mm (total)

Spline teeth length : 29.5mm from the side of the bridge
