Brand DSP
For Use With End Yoke Or Companion Flange
Series 1810
Material Steel
Spline O.D. 2.350
Number Of Splines 16
Involute N
Fits Tube Diameter 4.500
Fits Tube Wall .134
Spline End To Brg Shoulder (Y) 4.000
Spline End To Weld (K) In. 5.312
Spline Length (L) In. 2.750
Thread Size 1.250-18
Shoulder Diameter (B) In. 2.875
Shoulder Length (G) In. 1.312
Bearing Diameter (C) In. 2.362
Butt Diameter 4.243
Style 2
Bearing Diameter (Max) 2.3622
Bearing Diameter (Min) 2.3617
Weight 10.6 LB
