You are buying a Brand New Midship Stub Shaft
|
For Use With |
End Yoke Or Companion Flange |
|
Series |
1810 |
|
Spline O.D. |
2.350 |
|
Number Of Splines |
46 I |
|
Involute |
Yes |
|
Fits Tube Diameter |
4.500 |
|
Fits Tube Wall |
.134 |
|
Spline End To Brg Shoulder (Y) |
4.000 |
|
Spline End To Weld (K) In. |
5.312 |
|
Spline Length (L) In. |
2.625 |
|
Thread Size |
1.250-18 |
|
Shoulder Diameter (B) In. |
2.875 |
|
Shoulder Length (G) In. |
.812 |
|
Bearing Diameter (C) In. |
2.362 |
|
Butt Diameter |
4.242 |
|
Style |
2 |
|
Bearing Diameter (Max) |
2.3622 |
|
Bearing Diameter (Min) |
2.3617 |
Fast and free shipping to USA Contiguous!
One Year Warranty
No hassle 30 day returns
ISO Spec
