You are buying a Superior Quality Brand New Midship Stub Shaft
|
For Use With |
Outboard Slip Yoke |
|
Series |
1310-1480 |
|
Spline O.D. |
1.4370 |
|
Number Of Splines |
21/22 I |
|
Involute |
Yes |
|
Fits Tube Diameter |
3.5 |
|
Fits Tube Wall |
0.083 |
|
Spline End To Brg Shoulder (Y) |
7.715 |
|
Spline End To Weld (K) In. |
8.080 |
|
Spline Length (L) In. |
3.500 |
|
Shoulder Diameter (B) In. |
1.800 |
|
Shoulder Length (G) In. |
0.375 |
|
Bearing Diameter (C) In. |
1.575 |
|
Butt Diameter |
3.345 |
|
Style |
2 |
|
Bearing Diameter (Max) |
1.5751 |
|
Bearing Diameter (Min) |
1.5747 |
|
Bearing Diameter Length |
1.375 |
Superior Quality
One Year warranty
No hassle returns
