2-3-8001KX Spicer Driveshaft Slip Yoke 1310 series 16 spline 6.812 Center to End
2-3-8001KX Spicer Driveshaft Slip Yoke 1310 series 16 spline 6.812 Center to End
Couldn't load pickup availability
SPICER Driveshaft Slip Yoke 1310 series 1.375x16 spline 6.812 Center to End
Same as 2-3-5221KX but uses a push on style cap
Interchange parts numbers: N2-3-8001KX, 131N-3-8001KX, 2-3-8001KXB
Can be used with: 5-153X, 5-1310X, 15-1310-1X
Brand |
Spicer |
Series |
1310 |
Material |
Steel |
Outside Yoke Dimension (E) In. |
3.469 |
Bearing Cap Diameter (D) In. |
1.062 |
C/L To End Of Spline (J) In. |
6.812 |
C/L To Face Of Plug (F) In. |
1.500 |
Spline O.D. |
1.375 |
No. Of Splines |
16 |
Style |
SR |
VMRS |
024002038 |
Joint Angle #1 |
30.0 |
Package Qty |
1 |
Weight |
3.31 LB |
Features:
Heavy-duty flange yoke
Fast shipping to all US continental
Brand
Brand
Series
Series
Vehicle Make
Vehicle Make
Vehicle Model
Vehicle Model
VMRS
VMRS
Determine your Series
Determine your Series
Common U-Joint Series
Common U-Joint Series
Care Instructions
Care Instructions
All of our parts are packaged to the best of our ability. If you receive an item with inferior packaging, please let us know so that we can improve the delivery and our service to you as the customer
Shipping & Returns
Shipping & Returns
This item can be returned within 30 days of purchase. You are responsible for returning the item. No returns are accepted if rubber boots have been torn or damaged during installation. Please contact us if you are unsure of fitment prior to purchase
For orders with a cart value over $1000 contact us using the chat button below to reduce your shipping costs using our freight service
-
Free Shipping
We will cover the shipping costs on this item to all the USA contiguous States. We have you covered!
-
Check the OEM # of your part before you purchase
If you have no idea what the original part number is for your Driveshaft, CV Joint or Component - contact us for the appropriate diagram or for assistance. We are here to help!
