1310 Series Driveshaft Flange Yoke 2-2-479, 4x .438 Holes on 3.750BC, 2.750M
1310 Series Driveshaft Flange Yoke 2-2-479, 4x .438 Holes on 3.750BC, 2.750M
1310 Series Driveshaft Flange Yoke 2-2-479, 4x .438 Holes on 3.750BC, 2.750M

1310 Series Driveshaft Flange Yoke 2-2-479, 4x .438 Holes on 3.750BC, 2.750M

SKU: (2-2-479)-EB-USA-M-1
Regular price
$32.00
Sale price
$32.00
Shipping calculated at checkout.

You are buying a brand new flange yolk

Designed for 1310 series universal joints

Flange Yoke Specifications:

Series

1310

Flange Or Swing Dia. In. (A)

4.625

Bolt Circle Dia. In. (B)

3.750

Bolt Hole Dia. In (B)

.438 - DRILLED

Number Of Bolt Holes

4

Pilot Dia. M=Male F=Female (C)

2.750 - MALE

Flange Face To C/L In. (G)

1.375

Outside Yoke Dimension In.(E)

3.469

Yoke Bearing Dimension In. (D)

1.062

Design

Rectangular

Package Qty

1

Weight

1.46 LB
